RONCZ 1082 VOYAGER ROOT OUTER AFT WING AIRFOIL (r1082-il)

RONCZ 1082 VOYAGER ROOT OUTER AFT WING AIRFOIL - Roncz 1082 Voyager root outer aft wing airfoil


Airfoil r1082-il
Details Dat file Parser
(r1082-il) RONCZ 1082 VOYAGER ROOT OUTER AFT WING AIRFOIL
Roncz 1082 Voyager root outer aft wing airfoil
Max thickness 18% at 40% chord.
Max camber 3.4% at 40% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Lednicer format
RONCZ 1082 VOYAGER ROOT OUTER AFT WING AIRFOIL
      60.0      60.0

 0.0000000 0.0000000
 0.0004520 0.0039110
 0.0009510 0.0056950
 0.0019510 0.0082470
 0.0039490 0.0120530
 0.0079480 0.0180080
 0.0119460 0.0228400
 0.0199440 0.0307030
 0.0299420 0.0386930
 0.0399400 0.0455120
 0.0499390 0.0515320
 0.0599370 0.0569570
 0.0799350 0.0664820
 0.0999330 0.0746830
 0.1199320 0.0818710
 0.1399310 0.0882370
 0.1599300 0.0938990
 0.1799290 0.0989470
 0.1999290 0.1034390
 0.2199280 0.1074190
 0.2399280 0.1109260
 0.2599280 0.1139830
 0.2799280 0.1166120
 0.2999280 0.1188270
 0.3199290 0.1206340
 0.3399290 0.1220380
 0.3599300 0.1230420
 0.3799310 0.1236370
 0.3999310 0.1238070
 0.4199330 0.1235150
 0.4399340 0.1226940
 0.4599350 0.1212780
 0.4799370 0.1192710
 0.4999380 0.1167020
 0.5199401 0.1136460
 0.5399430 0.1102040
 0.5599450 0.1064680
 0.5799470 0.1024930
 0.5999490 0.0983210
 0.6199520 0.0939820
 0.6399540 0.0895040
 0.6599560 0.0849060
 0.6799590 0.0802120
 0.6999610 0.0754460
 0.7199640 0.0706200
 0.7399660 0.0657480
 0.7599690 0.0608440
 0.7799710 0.0559240
 0.7999740 0.0509970
 0.8199770 0.0460700
 0.8399790 0.0411800
 0.8599820 0.0362530
 0.8799840 0.0313740
 0.8999870 0.0265100
 0.9199890 0.0216500
 0.9399920 0.0167760
 0.9599940 0.0117840
 0.9799970 0.0061970
 0.9899990 0.0030520
 1.0000000 0.0000000

 0.0000000 0.0000000
 0.0004540 -.0037650
 0.0009550 -.0053450
 0.0019560 -.0073440
 0.0039570 -.0098130
 0.0079580 -.0129920
 0.0119590 -.0154700
 0.0199600 -.0195830
 0.0299620 -.0236230
 0.0399640 -.0268850
 0.0499650 -.0296500
 0.0599660 -.0320470
 0.0799690 -.0360490
 0.0999710 -.0392940
 0.1199730 -.0420120
 0.1399740 -.0443340
 0.1599760 -.0463420
 0.1799770 -.0480900
 0.1999790 -.0496150
 0.2199800 -.0509430
 0.2399810 -.0520930
 0.2599830 -.0530820
 0.2799840 -.0539250
 0.2999850 -.0546250
 0.3199860 -.0551910
 0.3399870 -.0556270
 0.3599880 -.0559420
 0.3799890 -.0561320
 0.3999900 -.0562000
 0.4199910 -.0561430
 0.4399920 -.0559630
 0.4599930 -.0556610
 0.4799940 -.0552340
 0.4999940 -.0546790
 0.5199950 -.0539890
 0.5399960 -.0531610
 0.5599960 -.0521910
 0.5799970 -.0510690
 0.5999980 -.0497720
 0.6199980 -.0482750
 0.6399980 -.0465240
 0.6599990 -.0444570
 0.6799990 -.0420410
 0.6999990 -.0392750
 0.7199990 -.0361780
 0.7399990 -.0328390
 0.7599980 -.0293590
 0.7799980 -.0258180
 0.7999980 -.0222890
 0.8199980 -.0188310
 0.8399980 -.0154910
 0.8599970 -.0123150
 0.8799970 -.0093480
 0.8999980 -.0066370
 0.9199980 -.0042310
 0.9399980 -.0021880
 0.9599980 -.0005910
 0.9799990 0.0003410
 0.9899990 0.0004080
 1.0000000 0.0000000
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

RONCZ 1080 VOYAGER INNER AFT WINGPreviewDetails
EPPLER 266 AIRFOILPreviewDetails
EPPLER 604 AIRFOILPreviewDetails
EPPLER 655 AIRFOILPreviewDetails
NACA 65(3)-618PreviewDetails
FX 66-17AII-182 AIRFOILPreviewDetails
FX 66-182 AIRFOILPreviewDetails
WORTMANN FX 66-17AII-182 AIRFOIL (ASPreviewDetails
EPPLER 603 AIRFOILPreviewDetails
AH 93-W-174PreviewDetails

Polars for RONCZ 1082 VOYAGER ROOT OUTER AFT WING AIRFOIL (r1082-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   r1082-il50,00094.2 at α=12°Mach=0 Ncrit=9Xfoil predictionDetails
   r1082-il50,000512.1 at α=14.75°Mach=0 Ncrit=5Xfoil predictionDetails
   r1082-il100,000925.4 at α=13.5°Mach=0 Ncrit=9Xfoil predictionDetails
   r1082-il100,000521.5 at α=12.25°Mach=0 Ncrit=5Xfoil predictionDetails
   r1082-il200,000960.9 at α=9.75°Mach=0 Ncrit=9Xfoil predictionDetails
   r1082-il200,000561.2 at α=8.5°Mach=0 Ncrit=5Xfoil predictionDetails
   r1082-il500,0009105.1 at α=9°Mach=0 Ncrit=9Xfoil predictionDetails
   r1082-il500,0005102.2 at α=7.75°Mach=0 Ncrit=5Xfoil predictionDetails
   r1082-il1,000,0009136.8 at α=8.25°Mach=0 Ncrit=9Xfoil predictionDetails
   r1082-il1,000,0005127.1 at α=6.5°Mach=0 Ncrit=5Xfoil predictionDetails
